●Maximum Input Pulse Frequency This is the maximum pulse frequency (speed) that can be input to the driver.
The maximum motor speed is limited by the driver, so if the exceeded frequency is input to the driver, the motor can no longer follow and the alarm is output.
●Photocoupler "ON" "OFF"
Input (output) "ON" indicates that the current is sent into the photocoupler (transistor) inside the driver. Input (output) "OFF" indicates that the current is not sent into the photocoupler (transistor) inside the driver.
H L Photocoupler State OFF ON Terminal Level
5 V
0 V
●Pulse Speed
For the pulse input type, the motor speed is proportional to the input pulse speed (pulse frequency).
Pulse speed f [Hz]= Number of pulses for 1 rotation of the motor × Speed [r/min]
●Deviation Counter
The deviation counter counts the deviation of the input pulse and feedback pulse inside the driver. When the pulse is input to the driver, the pulses are added by the counter (integrated pulse). When the motor rotates, the feedback signal subtracts the integrated pulse in the counter and perform the
positioning control so that the integrated pulse becomes 0.
●Hunting
During a standstill, the servo motor output shaft may vibrate slightly. This is called hunting.
●Settling Time
A delay occurs to the positioning command of pulse input and the actual motor
operation. The settling time is the time difference that occurs at a motor
standstill.
